Order Picker

Pick Your Way

The Toyota Order Picker easily maneuvers narrow aisles in warehouses with minimized rack impact during case picking thanks to optional wire guidance and double rail guidance systems.  You’ll also drive to optimal efficiency with optional Lift Logic technology that continuously monitors lift height, allowing for optimized travel speed at various lift heights while still maintaining safe operation.

Load Capacity 3,000 lbs.
Electrical  System 36 / 48V
Length to Forkface 74 – 83.75″
Overhead Guard Height 88.25″
Overall Width 40 – 60″



Request a Quote

Don’t know exactly what you need? Not to worry. A member of our team will contact and assist you.

Model
Number
Load Capacity*
(lbs)
Max Travel Speed
Full Load (mph)
Max Lift Speed
Full Load (fpm)
Max Gradeability
Full Load (%)
Basic Right Angle
Stack** (in.)
8BPUE15 3,000 6.5 33 N/A N/A
8BPU15 3,000 6.5 37 N/A N/A
8BPUH15 3,000 6.5 80 N/A N/A

* Based on 24″ Load center
** Add load length and clearance

Product specifications may not reflect the most current product details. All specifications should be verified by Shoppa’s Material Handling prior to purchase.

Performance

  • 24 Volt electrical system 2
  • 36 Volt electrical system 3
  • Independent lift, drive, and steer motors
  • AC drive motor
  • AC lift motor 4
  • DC series wound lift motor 5
  • Regenerative braking
  • Multi-function control handle
  • Fully variable lift/lower controls
  • Programmable performance
  • Hydraulic mast lowering deceleration
  • UL “E” rating

Ease of Service

  • 4 function hour meter
  • No tools, high-impact service access covers
  • On-board diagnostics
  • Battery compartment rollers
  • Emergency manual lowering valve

Safety

  • Full body harness and energy-absorbing tether
  • Electronic disc brake
  • Wire mesh mast guard

Ergonomics

  • Cushioned mast staging
  • Bubble cushioned floor mat
  • Anti-rattle mast
  • Spring platform suspension system
